Lifting Shoulder EyeBolt With Metric Thread Din 580 36m 5.1T

FEATURES:

• Galvanised finish
• Specifications, batch and brand markings as per Australian Standards requirements
• Tested and certified to AS 2317

SPECIFICATIONS:

• Thread: M36
• W.L.L (t): 5.1
• Dimension D (mm): 36
• Dimension D1 (mm): 70
• Dimension D2 (mm): 75
• Dimension D3 (mm): 28
• Dimension H (mm): 128
• Dimension H1 (mm): 54
• Dimension W (mm): 126

Part Number/SKU: TM9240-02360

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.
