Lifting EyeBolt With Metric Thread Din 580 10mm 0.23T ITM TM9240-02100

FEATURES:

• Galvanised finish
• Specifications, batch and brand markings as per Australian Standards requirements
• Tested and certified to AS 2317

SPECIFICATIONS:

• Thread: M10
• W.L.L (t): 0.23
• Dimension D (mm): 10
• Dimension D1 (mm): 25
• Dimension D2 (mm): 25
• Dimension D3 (mm): 10
• Dimension H (mm): 45
• Dimension H1 (mm): 17
• Dimension W (mm): 45

Part Number/SKU: TM9240-02100

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.
