BM16 Portable Beveller 240V 2.2KW Motor WA-BM16

Mill edges of plates and pipes made of steel, aluminium alloys, brass, or plastic. Continuous bevel width adjustment. Overload protection. Electronic speed control Each standard milling head uses 5 indexable cutting inserts. Bevelling radius milling head enables bevelling edges with radius of 2, 3, 4 or 5mm with use of 4-sided indexable R2, R3, R4 or R5 cutting inserts. Highly efficient for edge weld preparation and rounding off steel construction before painting or coating.

SET INCLUDES

  • BM-16 beveling machine without milling head or cutting inserts
  • Metal box
  • 32mm flat wrench
  • Allen wrench hex s=5
  • Allen wrench hex s=14
  • Operator’s Manual

SPECIFICATIONS

 POWER SUPPLY   220V-240V / 50-60Hz
 MOTOR   2200 W
 SPINDLE SPEED   1800-5850 rpm
 MINIMAL MATERIAL THICKNESS   1.5 mm
 MINIMAL INTERNAL BEVELLING   40 mm
 MAXIMUM BEVEL WIDTH   16mm
 BEVEL ANGLE (Depending on Miling Head)   20°/ 22.5°/ 30°/ 37.5°/ 45°/ 50°/ 55°/  60°/  65°
 MINIMAL DIAMETER OF COUNTERSINKING   ca 40mm
 ROUNDING EDGES    R2, R3, R4, R5
 DIMENSIONS L x W x H   585mm x 156mm x 238mm
 WEIGHT   10 kg




Part Number/SKU: WA-BM16

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.

SKU WA-BM16
Brand ITM
Shipping Weight 12.0000kg
Shipping Width 0.300m
Shipping Height 0.400m
Shipping Length 0.700m
Unit Of Measure ea
