EM50 RL-E Magnetic Drill Excision 18612

DESCRIPTION:

The EM50 RL-E is all about versatility. Its forward-reversible gearbox makes tapping easy, while the variable 2-speed gearbox provides precise control for different hole diameters. Equipped with a Morse Taper 2 spindle and a solid 16,000N magnetic adhesion, it’s built for a range of tough drilling tasks.

FEATURES:

2-speed variable oil bath gearbox
Forward-reversible drive, ideal for tapping
3 coil 16,000N magnetic adhesion
Solid brass guides with spring loading for rigid gliding and no vibration
Morse Taper 2 spindle

SPECIFICATIONS:

Core Drill Dimensions	12.0-50.0mm
Cutting Depth	50.0mm
Twist Drill	With a quick-release chuck up to 20.0mm with MT3 DIN 345 direct
Counter-Boring	10.0-40.0mm
Tapping	Tapping Chucks: M3-M14 with tapping attachment: M3-M20
Arbors	MT2
Stroke	170mm
Height Adjustment	100mm
2-Speed Gearbox	Right/Left 1. Step 100-250rpm 2. Step 180-450rpm
Power Consumption	1,200W
Voltage	230V 50/60Hz
Tool Force (10mm)/Magnetic Adhesion Strength	3,800N/16,000N
Magnetic Base	92×238mm
Weight	16.0Kg
Gearbox Direction	Forward-Reverse
Magnet Type	Electric
Shank Type	Morse Taper 2

Part Number/SKU: 18612

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.

SKU	18612
Brand	Excision
Shipping Weight	45.0000kg
Shipping Width	0.600m
Shipping Height	0.800m
Shipping Length	0.800m
Unit Of Measure	ea
